Uniformation GK THREE ULTRA Preview (GK3) - Big is Back - Because BIGGER IS BETTER
Jul 24, 2024
BUY the Uniformation GKTHREE Ultra Here from July 24: https://geni.us/UniformationGK3
DISCOUNT CODES BELOW!!!
$100 off - "FauxHammerGK3U100"
*NOTE:* The GK3 Ultra printer comes with PFA Release film, thanks to "your" feedback.
*GKTWO"
BUY the Uniformation GKTwo Here: https://geni.us/Unfomation
"FAUXHAMMER" - $120-off a GKTWO Printer
"FAUXHAMMER" - $120-off a GKTWO with Wash an Cure
Please support us by clicking our links to check out Loot Studios
*Loot Studios Sci-Fi* - https://geni.us/LootStudiosSciFi
*Loot Studios Fantasy* - https://geni.us/LootStudiosFantasy
*Loot Studios Freebies* - https://geni.us/LootStudiosFreebies
Get any printer working easily with the Photonsters XP Range Finder - https://www.thingiverse.com/thing:6023738 (watch my video for full instructions https://youtu.be/Gm0-z971tgY)
Join this channel to get access to perks:
https://www.youtube.com/channel/UC_9Jsf3SP8aMJgn0xv5jHjA/join
Show More Show Less View Video Transcript
0:00
okay here we are now I know I already
0:03
did a live stream and sorry about the
0:04
pop-up size in that but this is a more
0:07
formal approach of announcing the latest
0:10
uniformation printer the gk3 ultra if
0:14
you've been on the fence it's probably
0:15
time to get off especially since this is
0:17
potentially the do everything machine
0:19
that people have wanted for a long time
0:22
let's crack on with it hi I'm Ross and
0:25
this is fa Hammer videos first a
0:28
disclaimer before we begin cuz this
0:30
isn't one of my usual videos this is not
0:32
a review it can't be a review because I
0:34
only have a prototype unit this specific
0:37
unit has had some quirks I've had to
0:39
work through and many of the components
0:41
are 3D printed sample pieces in fact
0:44
I've had it in pieces and back and I've
0:46
worked with uniformation to highlight
0:48
any potential snags the units that go
0:51
out to everyone including me as review
0:53
samples will have most of these things
0:55
resolved some will come later via
0:58
software updates and others based on
1:00
your feedback too so again not a review
1:03
which means no critical analysis from me
1:06
here this is full promotion on behalf of
1:09
uniformation if you want my critique it
1:11
will come after we get release units I
1:14
just don't want people telling everyone
1:16
I'm raving about this when my job today
1:19
is to do no more than show it I've not
1:21
been paid for this video but after the
1:23
stunning success of the gk2 I've kind of
1:26
been gunning to promote their next
1:28
printer this one what you will get to
1:31
see today are all of the present and
1:33
upcoming features of the machine and if
1:35
you spot anything I've missed or you
1:37
think could be an issue add it in the
1:39
comments I'll strive to answer everyone
1:41
and uniformation are watching okay all
1:45
that out of the way let's get on so
1:47
they've done it and they were the first
1:49
to do it too uniformation have brought
1:51
the pixel resolution of smaller printers
1:54
to a large format 13 and 1/2 in printer
1:57
this thing prints huge models with its
2:00
generous build area of
2:02
302x 162 by 300 mm the resolution of
2:07
this machine is
2:08
15,120 X
2:11
6,230 pixels below the screen is a
2:14
matrix LED UV array so this is a 16k
2:19
display but like most modern printers is
2:21
only 16k on the x-axis the pixel size is
2:25
20 microns on X but only 26 on y giving
2:29
this printer AVC of 26 microns that's
2:32
just two Micron shy of modern 10in
2:35
printers and they 12K or 4 ink displays
2:39
they have an AVC of 24 microns and the
2:42
next highest resolution printer for a
2:44
printer of this size is something like
2:46
the mega 8K at 43 microns than the
2:49
Jupiter at 51 and if you're new to
2:52
Printing and you want to know what ABC
2:53
means check out my 12K printers are a
2:56
relevant video but please skip to about
2:58
7 Minutes in cuz the beginning is very
3:00
boring but the point is regardless of
3:02
the 16k this isn't this is the first
3:06
printer of this size to bring us this
3:08
quality and the next best is almost half
3:11
as much and we're going to go through
3:13
the features and honestly guys I'll
3:15
forgive anyone who says that this is
3:16
just a bigger gk2 because that's a fair
3:19
and accurate assessment now on the
3:21
positive side of this I expect many
3:23
recent gk2 buyers won't be looking at
3:26
this machine and thinking I've missed
3:28
out because you'll get about the same
3:30
print quality on the two as you will on
3:32
the three Ultra it's just the size
3:34
difference along with a couple of new
3:37
features and what makes the gk2 and gk3
3:40
Ultra great is more than just the heater
3:44
as many gk2 owners will attest to its
3:47
sensible design choices leading to a
3:49
simpler and smoother printing experience
3:52
speaking of the features let's walk
3:54
through them so you've got the heater
3:56
first and foremost the way this works is
3:58
that the chamber below the LCD is warmed
4:01
up and heat passes through the LCD to
4:04
warm the resin from below the
4:06
temperature is monitored by a small
4:07
sensor within the frame area of the LCD
4:10
now I did ask them why not a heated vat
4:13
this time and I was told by uniformation
4:15
that heated Vats are good but they warm
4:18
from the sides of the vat which can lead
4:20
to inconsistent resin temperature across
4:23
the whole surface and apparently heating
4:25
from the circulated heat in the chamber
4:28
below leads to a more even spread of
4:30
warmth and that makes sense to me and
4:33
the CI got in GCSE physics but if you
4:36
know better let me know down in the
4:38
comments please I haven't tested this
4:40
theory on a printer with a heated VAP
4:42
because I've only recently gotten a
4:44
thermal camera and in this case the heat
4:46
seems fairly evenly spread but yes heat
4:49
can also reduce the life of an LCD but
4:52
for anyone with this argument come on
4:55
guys it's 30° there are people in the
4:57
world who live in environments hotter
4:59
than this in fact I bet many would love
5:01
it if it was that cool so yeah heat
5:04
shortens the life of electronics but
5:06
instead of pointing out how this printer
5:08
kills the screen let's be a bit more
5:10
realistic in regard to what degree this
5:13
heat actually has an impact I mean the
5:15
resin gets hot as it cures you know and
5:17
that's in all printers but let's say you
5:19
do need to replace the screen well in
5:21
typical uniformation fashion this is a
5:24
case of unscrewing the screen
5:25
disconnecting a ribbon cable then
5:27
putting a new one in LCDs are
5:29
consumables in 3D printers after all but
5:32
screen replacement in this one is easier
5:35
than in every other printer out there
5:37
except the gk2 because that one has two
5:40
fewer screws than this a quick look at
5:42
the lid shows us we now have a robustly
5:44
hinged up and over unit which is more in
5:47
line with modern machines than the gk2
5:50
though when this is open you will need
5:52
77 cm of height and 47 cm of depth in
5:55
your work area the machine is 45 cm wide
5:59
if you're looking for the dimensions now
6:01
I've already seen people say in the
6:02
comments on my other video that it's a
6:04
no for them because they need to rack
6:06
mount printers but uniformation have
6:09
designed this in such a way that you can
6:11
just remove the two hinge screws from
6:13
each side and then you have a removable
6:15
face plate instead which is still much
6:18
less to store elsewhere than a whole lid
6:21
making this incredibly accessible for
6:24
home users and print Farms alike see I
6:27
told you these guys were smart however
6:29
and perhaps in contrast to that
6:31
assessment I do need to point out that
6:33
whilst the lid has a built-in handle for
6:35
opening it one-handed and draft excluder
6:38
strips down the side to keep heating the
6:40
handle currently has a big gap allowing
6:43
you to get your fingers inside the
6:45
printer and allowing the warmth and
6:47
potentially toxic fumes out now
6:50
uniformation have realized this when I
6:53
pointed it out to them and whilst the
6:55
demo units going out to other creators
6:58
still have this issue the Gap will be
7:00
properly covered before production units
7:02
start to ship and yes you'll still have
7:05
a handle but you should have seen their
7:07
reaction when I pointed this out to
7:10
them another Tiny But handy feature is
7:12
the bullseye spirit level on the front
7:14
right corner of the machine coupled with
7:16
the adjustable legs you can now get the
7:18
printer itself even on pretty much any
7:21
work surface right then moving inside
7:23
the printer we have a very large bed
7:26
this design is very similar to that on
7:28
the gk2 but much larger no getting resin
7:31
on the top of this build plate however
7:34
the leveling mechanism has moved from
7:36
the plate itself and is now part of the
7:38
Z arm it's pretty much the same
7:40
mechanism and leveling method as before
7:42
but now it's moved so you can actually
7:44
see the screws and there is no Auto
7:47
leveling in this machine but there's
7:48
also no true Auto leveling in any resin
7:51
printer that I've seen yet and before
7:53
you call me a uniformation shill I've
7:55
said this in every resin printer review
7:58
that said it's got Auto leveling but at
8:01
least this one comes pre-leveled what
8:03
this printer doesn't have however is any
8:06
form of pressure detection features the
8:09
bill plate Clips to The Zed arm with a
8:11
large lever which is Handy for
8:12
one-handed operation what I can't show
8:15
you though are the Dual linear rails or
8:17
the ball screw yes this has a ball screw
8:20
not a lead screw this printer has these
8:23
things but they are actually all covered
8:25
to prevent any errant splashes of resin
8:28
from gumming up the mechanism the vat is
8:30
quite large and whilst mine here reads
8:32
Max 900 milliters the final version will
8:35
allow for one lit of resin as the
8:38
maximum in the vat and as I write this
8:41
they're still deciding whether the
8:43
printer will come with PFA or ACF by
8:45
default mine and the first sample models
8:48
they send out will be ACF now if you
8:51
don't know what this is ACF will reduce
8:53
the peel forces which speeds up Prints
8:56
but it leaves surface marks on models
8:58
however for for a printer of this size
9:00
well will many people actually buy it
9:03
for printing small detailed models in
9:06
which case those small surface marks are
9:08
a moot point but what I do know for
9:11
certain is that you can buy extra PFA or
9:13
ACF sheets for this machine and you can
9:16
actually buy extra Vats which come with
9:18
either ACF or PFA pre-installed you just
9:22
decide which one you want if you buy
9:24
this printer during its pre-order window
9:26
I'll have exclusive codes that you can
9:28
get either free resin or free release
9:31
film should you want to use the
9:32
alternative those along with my
9:34
affiliate links will be down in the
9:36
description please make sure you check
9:37
them to get your freebies with your
9:39
purchase and just to advise I have used
9:42
both ACF and PFA in this machine this
9:45
vat now Clips to the chassis using
9:47
latches along its thick metal frame so
9:50
no more breakable clips and the whole
9:53
print bed will actually slide into a
9:55
slot on the left hand side of the bill
9:57
plate then slide into a notch on the
9:59
upper chassis allowing the vat to become
10:02
a drip tray and this is the first
10:03
printer of this size to have a sensibly
10:06
oriented method for a drip tray most
10:09
leave the prints dangling at an odd
10:10
angle restricting you to smaller parts
10:13
or having larger Parts still sat in the
10:15
resin and touching the screen here by
10:18
holding it horizontally the full 300 mm
10:21
of build height is covered by the 300 mm
10:24
of the width of the vat and then some
10:26
cuz the vat's actually quite wide now as
10:29
for speed the metrics quoted to me are
10:31
30 mm per hour for 0.1 mm layers which
10:36
Compares it via the same BS metric that
10:38
other brands use but nobody prints at a
10:41
more sensible measure is 60 mm per hour
10:44
for 50 Micron layers uniformation have
10:47
advised me that they've focused on print
10:49
quality rather than speed for this
10:52
machine now then as for the UI right now
10:56
as I've got it this is still the exact
10:58
same UI y as the gk2 but it's not
11:01
finished and uniformation are now
11:03
concentrating on additional features
11:05
which will be added for when the printer
11:07
goes on General release and the
11:09
uniformation UI was already fairly solid
11:12
but a bit basic compared to Modern
11:14
standards put your USB drive in and
11:16
choose a file to print the machine will
11:18
then copy this file to internal storage
11:21
and verify its Integrity you can then
11:24
remove the USB drive as you wish whilst
11:26
continuing with your print and as of
11:29
right now you can still set up the
11:30
printer's 7 GB internal storage as a
11:33
network drive on your PC this allows you
11:36
to copy files to it remotely using the
11:38
ethernet connection or USB Wi-Fi dongle
11:41
that comes included with the printer but
11:44
uniformation are working with both
11:46
chitubox and lchi to integrate with
11:48
their more automated Network systems so
11:51
you can send files start a print and
11:53
monitor print progress remotely from
11:55
within the slicer and they've also told
11:57
me they're adding the ability to to edit
11:59
a sliced file settings directly from the
12:02
UI and the one I think most of you will
12:04
like is the fact that they're adding the
12:06
ability to run multiple exposure time
12:08
tests in a single print yeah I thought
12:11
that wanted impress you I'm certainly
12:13
looking forward to testing that out so
12:15
that's pretty much the gk2 with some new
12:17
features coming but this one has some
12:20
new features so let's get on to them
12:22
we've got two one is an LED light bar
12:25
which can be turned on and off from the
12:27
UI this sits at the top of the pr
12:29
above the vat and behind your prints now
12:32
on an unrelated note remember how I said
12:34
if you can spot anything you think could
12:35
be an issue let me know in the comments
12:37
yeah just reminding you now we've
12:39
reached this far through the video no
12:40
reason it's not related to the LED thing
12:42
at all honestly the other new feature
12:44
though is the resin system now let me
12:47
sort something out as I've already been
12:49
accused of being a uniformation shill on
12:52
my announcement video
12:54
because I typically hate anything
12:57
measured in K but I like 16 okay here I
13:00
hate ACF but I like it here and I hate
13:03
resin pumps but I like them here that
13:05
was a comment I got on a video let me be
13:07
clear well as clear as I was in the live
13:09
stream that this commenter clearly
13:11
skipped through and I've already said
13:14
this is not a critical review I don't
13:17
love the term 16k I've already said this
13:20
isn't 16k what I like about this printer
13:23
is that the AVC is 26 microns and I
13:27
don't suddenly love ACF but but like I
13:29
already said in another larger format
13:31
resin printer review it does make more
13:34
sense when you're printing large things
13:37
and I don't love resin pumps because I
13:40
don't like the mess they cause and their
13:42
speed limitations but with this one
13:46
they've solved several of the resin pump
13:48
problems I have you see resin pumps
13:50
usually only work with one bottle type
13:52
or you need to leave your resin bottle
13:54
open near the printer this printer comes
13:57
with an empty storage bottle which you
14:00
can fill up with your own resin using
14:02
the spout which is included with the
14:04
printer and you can buy extras of these
14:07
if you so wish but the best part is that
14:10
this bottle with your resin in or
14:12
uniformation own which now comes in
14:15
these Square cassettes plugs in at the
14:17
top at the back of the printer and this
14:19
is pressurized to ensure that it pumps
14:22
all of the resin out of the bottles but
14:25
this also ensures that when you remove
14:27
the bottle there are no beaks or drips
14:29
to worry about and I like that and
14:32
further to this the system has the
14:34
ability to pressurize and Purge the
14:36
lines to reducing any chance of
14:39
cross-contamination to a bare minimum
14:42
and you can flush it further if you like
14:44
by filling an empty container with a
14:46
cleaning solution though in my testing I
14:49
couldn't see any drops of wargamer resin
14:51
in my red Frozen resin when I tried this
14:54
function out oh and it also weighs the
14:56
bottle when you put it into the machine
14:57
to estimate how much you have in it at
15:00
all times and this has seemed fairly
15:02
accurate so far and it's helpful because
15:05
there's a calibration function built
15:07
into the UI so as far as resin filling
15:10
systems go this is by far the cleanest
15:13
I've ever used and because it only
15:15
refills the system when you have a very
15:17
small amount left in the base of the vat
15:20
this makes heating a little more
15:22
efficient too because there's less resin
15:24
to warm at any given time now I need to
15:27
say here I had a bit of an argument with
15:29
uniformation we'll call it a
15:31
disagreement but it's one where they
15:33
kind of proved I was in the wrong you
15:36
see I thought the printer shouldn't warn
15:38
you that you don't have enough resin
15:40
before a print which is what it does it
15:42
warns you and I thought it shouldn't do
15:44
this especially when a bottle is nearly
15:46
empty I felt that because it takes the
15:49
estimated volume from the slicer file
15:51
and Compares that to the volume of the
15:53
resin in the bottle only not the vat it
15:57
should let you print regardless and then
15:59
just pause when the bottle runs out and
16:01
let you swap it but as they correctly
16:03
pointed out much like one of my
16:05
commenters who goes by a while Tom
16:07
appeared and is also one of the guys
16:09
behind table flip foundaries testing for
16:11
things like the cones of calibration
16:13
among other much more technical resin
16:16
printer things what they told me is that
16:18
when a print pauses you can get lines in
16:21
your print now I know that but it's not
16:23
because of accuracy in the printer but
16:25
because of things like temperature
16:27
changes to the resin between layers and
16:28
and also its exposure to oxygen or its
16:32
time sitting in a pool of warm resin
16:34
waiting the longer the pause the more
16:36
likely this type of line will occur so
16:39
basically you don't want a print sat on
16:41
Paws for ages waiting for you to notice
16:43
and then swap a bottle over so to avoid
16:46
this they warn you before a print what
16:48
the volume of the print is versus what
16:50
you have in the printer if this is more
16:52
than the 1.2 L these uniformation
16:54
bottles hold at Max you might have a bit
16:57
of math to do remember you can have up
16:59
to a liter of resin in the vat plus the
17:01
1.2 L in the bottle so as long as your
17:04
print is less than that you're fine and
17:07
even on a printer this big 2.2 L is an
17:11
excessive amount of resin for a single
17:13
print if in the very unlikely scenario
17:17
you need more than that yeah you need to
17:19
remember to top it up and if say you
17:22
have half a bottle of resin left before
17:24
a print and this is telling you that you
17:26
don't have enough the recommendation
17:28
from UNIF formation was to purge the
17:30
excess and then put in a fresh bottle so
17:32
you always have a full bottle in waiting
17:35
now maybe this seems like a lot of faf
17:37
and fair enough you might like just
17:39
pouring resin in and pouring it out
17:41
don't worry you don't need to use any of
17:43
this it is completely optional and you
17:45
can turn it all off completely in the
17:48
menus and just pour resin in and out
17:50
manually or you can leave it on and
17:53
you're still allowed to print by just
17:55
clicking ignore to all of the warnings
17:57
so that's the printer let's let's touch
17:59
on the wash and cure systems The Cure
18:01
system is simple it's the same as the
18:03
last one they made but bigger I already
18:05
have a video showing the previous cure
18:07
station feel free to watch that and
18:10
imagine it's bigger but what do you want
18:12
to know about this really it's a box
18:14
with UV lights in and a turntable in it
18:17
you set on the front how long you want
18:19
it to run for and click Start easy
18:22
simple big now this one is also
18:24
compatible with uniformation filter
18:26
cartridges that slot on the back just
18:28
like the pr
18:29
the same size and same shape ones fit
18:31
here and this also has a heating
18:33
function in this one for drying but even
18:35
uniformation recommend you to pre-dry
18:37
your models with a hair dryer which
18:40
personally I think says enough about the
18:42
drying function of this device the lid
18:44
opens on top not the front now as for
18:47
the wash station this is a bit more
18:49
complex for big prints you will
18:51
obviously need a bigger wash and cure
18:53
station from the norm now I've not
18:56
managed to get this fully operational
18:58
yet but the idea is you fill up the
18:59
large buckets with water the system
19:02
fills the chamber with fluid it lowers
19:04
the build plate into the fluid washes it
19:06
for a maximum of 3 minutes using an
19:08
impeller then raises the bed up flips it
19:11
180° and submerges it again for the same
19:14
wash time once the Cycle's complete the
19:17
water drains back into the container and
19:20
you can also use the included basket
19:22
with parts like in most other resin
19:24
cleaning units let me once again remind
19:27
you though that no particular Reon
19:28
reason this is not a critical review of
19:31
any of these devices I have actually
19:33
reviewed one like this before I'd
19:35
recommend checking that out for a better
19:37
idea of how this kind of system works as
19:40
for print quality well I printed a few
19:42
large items using wargamer resin I
19:45
started with a miniature this model of
19:47
Lord narcissus created by the wonderful
19:49
people at Titan Forge and then I printed
19:51
a larger version then I printed parts
19:53
for a stupidly large version for no
19:56
other reason than I could and by the way
20:00
if you buy this printer this model comes
20:02
bundled with it among others do you dare
20:05
print one this big please don't now I
20:07
also used Frozen's hyperfine resin to do
20:10
some exposure tests to measure the XY
20:12
accuracy you will find this comparable
20:15
with the correct English meaning of that
20:17
word to smaller 8K to 14K printers feel
20:21
free to pause the video and take a
20:22
screenshot of this flat test then you
20:24
can compare it to other resin printer
20:26
reviews that I've done and so to f
20:28
finish let's talk about the price now we
20:31
were told not to say anything about this
20:33
until release and it may have been
20:35
revealed before now if not let me tell
20:37
you what it is if you're watching this
20:40
video within the first 2 days of the
20:42
printer going on sale you can pick it up
20:44
now bear in mind the gk2 was
20:47
849 you can pick up the gk3 ultra for
20:53
$999.99 or local equivalent near enough
20:57
and this pre-order price price is for
20:59
those first technically 3 days due to
21:02
time zones but for those first 3 days
21:04
whilst pre-order stocks last so I would
21:08
highly recommend be verying quick if you
21:12
want it that cheap just remember to use
21:14
our affiliate links and make sure you
21:16
use one of the codes in the description
21:18
of this video to get your free gift
21:20
during this period after this super
21:23
early bird period it will then go up to
21:25
a pre-order price of 1,1 99 but this is
21:30
still at a discount when the products
21:33
finally released the recommended retail
21:35
price goes up to
21:39
1,299 so you can understand uniformation
21:42
are really gearing up to get a lot of
21:44
those early sales so if you want it for
21:46
that price like I said stock could be
21:49
limited for a certain amount to go so
21:52
cheap so yeah not trying to do the fomo
21:55
thing but if you want it that cheap get
21:57
it that cheap now because it it ain't
22:00
going to be that cheap again for a long
22:01
long time if ever but there you go guys
22:05
that's the printer and its accessories
22:07
but that's the printer it's available
22:10
pretty much now so if you like it and
22:13
you want it get your ass over there and
22:15
get it please as I said click our
22:17
affiliate Link in the description and
22:19
I'm not getting paid to make this so I
22:22
only get paid if you decide to go and
22:24
buy it and use that link now for
22:26
everyone else maybe you like it but but
22:28
are still on the fence if so please look
22:31
out for my full critical review coming
22:34
soon I want to say thanks for watching
22:36
with a huge thanks to our members who
22:37
are on screen now I'm going to wrap this
22:39
one up here so you can rush off and buy
22:42
the printer see you guys next time faux
22:44
hammer out
22:50
[Music]
