Up next in 10
Check out the *Colour Prints* Catologue on Only-Games . co here https://geni.us/OnlyGamesColour
StrataSys J55 Prime: - https://www.stratasys.com/uk/3d-printers/printer-catalog/polyjet/j55-prime/
*If you enjoy hearing my opinions about hobby stuff, you can listen to more on* @thepaintingphase
Huge Thanks to the following Creators
TitanForge for Sculpting this model - https://titan-forge.com/
Printed Obsession for Digitally Painting this Sculpt - https://geni.us/PrintedObsession
Thanks to the following creators for help with the Thumbnail for this video
@RisingApe
@ThePaintingCoach
@HellstormWargaming
@thepaintingphase
@ArtisOpus
Get any printer working easily with the Photonsters XP Range Finder - https://www.thingiverse.com/thing:6023738
- Watch my video for full instructions https://youtu.be/Gm0-z971tgY
Show More Show Less View Video Transcript
0:00
full color resin printing is here and
0:02
I'm not talking about 4 to 16 flat
0:04
colors like in fdm printing I'm talking
0:07
about 640,000 distinguishable color
0:10
combinations across the surface of
0:13
detailed models whether you're looking
0:15
to make a single prototype part in a
0:17
specific tone or a fully painted
0:20
detailed miniature yeah that's what this
0:23
does I just heard myself speak there and
0:25
I'm reading my own script and I realize
0:27
this sounds like a sales pitch but look
0:29
the point is I get it this is not for
0:31
everyone and I know for a fact that many
0:33
people out there like me enjoy painting
0:36
models that they 3D print but even if
0:38
that's the case you've still got to
0:40
admit from a technology standpoint alone
0:43
this is flipping call and obviously I
0:46
don't mean flipping but I'll get
0:47
demonetized for swearing in the first 30
0:49
seconds so instead of a review of this
0:52
machine I just want to show off how this
0:54
amazing technology works because you can
0:56
already order prints from one of these
0:58
machines at very reasonable prices but
1:01
we'll get to that and also just a
1:03
reminder if you watch this video before
1:05
UK games Expo 2024 I'll be providing
1:08
details in this video of how you can get
1:10
a free 3D model of me from me to add to
1:14
your collection so if you don't care and
1:17
you don't know who I am hi I'm Ross and
1:20
this is f Hammer videos right so as you
1:23
may know I recently visited my mini
1:25
Factory I've done a video on this and
1:26
that video talked about this video being
1:28
next but with all the new printers that
1:30
have come out in the last month and my
1:31
general lack of time management skills
1:34
this video may actually be out first who
1:36
knows feel free to laugh at my
1:37
ineptitude in the comments so right as
1:41
you may not know I recently visited my
1:43
mini Factory their partner side only
1:45
games cells made to order physical
1:47
models for those of you who want the
1:49
ability to get these 3D printed models
1:51
but don't want to go through the hassle
1:53
of 3D printing them yourself and I know
1:55
those people out there exist because
1:56
well they comment on my videos all the
1:58
time I get so many comments saying I
2:00
love the idea of 3D printing I just
2:02
don't want to own a 3D printer yeah fair
2:05
enough I understand that but you've got
2:07
to admit a lot of us see the benefit of
2:09
3D printed resin models 3D printing has
2:12
already given us models with more detail
2:14
and often less cleanup than their
2:15
plastic counterparts even I'd love to
2:18
just have a model arrive at my door
2:19
immediately ready to be painted that's
2:22
actually the largest part of my hobby
2:24
but I suspect there are also numerous
2:26
people out there who would like a model
2:28
or even an army to arri dri at their
2:30
door ready painted and ready to play
2:32
with or just have a big one-off model
2:35
like I got as a standy for my desk but
2:37
regardless of anyone's reason for
2:39
wanting or not wanting one of these
2:41
prints as I said are we 30 seconds in
2:44
now yeah awesome this technology is just
2:47
so cool and the thing I really
2:49
want to convey for those of you who are
2:51
less interested in the miniatur side of
2:53
this hobby this printer has some
2:55
incredible features which showcase the
2:57
potential future of Home resin printing
3:00
because this process is literally drop
3:02
the colored model into the slicer
3:04
application remotely send it to the
3:05
printer and click print when it's done
3:08
you can remove the model with your bare
3:10
hands and just rinse it in water to
3:12
remove all of the support material how
3:14
cool is that also how does this actually
3:18
work well in this case only games have
3:20
been working with stratasys for months
3:22
now to refine the color output of this
3:24
machine and this machine is one of
3:26
several different J5 models from Strat
3:29
assist it's an industrial grade system
3:31
developed for use in dental medical and
3:33
prototyping Industries only games are
3:36
using it to deliver fully painted models
3:39
and this is the sort of machine where
3:41
you won't find the prices of it online
3:43
it's call for a quote and the resin
3:45
material that's put through it can
3:47
actually cost more per liter than some
3:49
3D printers I've reviewed now admittedly
3:52
that's the really cheap crappy ones and
3:55
this isn't something that you'd buy and
3:56
put on a desktop anyway standing at over
3:59
one .5 M tall with an area of 651 by 661
4:05
mm this unit is the size of a small
4:07
fridge and yes you need it because the
4:10
lower half is where you install up to 12
4:12
resin cartridges there are a ton of
4:15
materials available for this machine
4:17
with various properties for different
4:18
applications but only games are using
4:21
black white cyan magenta and yellow
4:23
along with a bay for support material
4:26
the second load of Bays below this is
4:28
used for redundancy so when one cart
4:30
runs out it moves onto the next one so
4:32
you can swap them out without having to
4:34
pause or delay prints now I hope the
4:36
build quality of this machine goes
4:38
without saying if you need proof of its
4:39
robustness then check out the frame for
4:41
the Z axis we talk all the time about
4:44
printers with single or dual linear
4:46
rails this thing has what I can only
4:48
describe as Pistons now you may be
4:52
wondering about the odd shape of this
4:53
machine and why it looks like some crazy
4:55
vinyl record player because I was also
4:58
confused now it took a few explanations
5:01
for me to understand how this works and
5:03
it was only when I saw it in person that
5:05
I could actually grasp what it does this
5:08
prints like no other resin printer I've
5:10
seen before you can forget your SLA Mast
5:12
SLA and DLP Technologies this process as
5:15
has been trademarked by stratasys is
5:18
referred to as polyjet printing now from
5:21
the specs I was able to gather online
5:23
for this machine the build area is
5:25
stated as 140x 200x 187 mm but seemingly
5:30
that's just the maximum size of a single
5:32
printed component you can actually
5:34
duplicate that build area several times
5:37
around the spinning build plate don't
5:40
worry if this still makes no sense
5:41
because I'll show how it works using the
5:43
footage I captured and some of the 3D
5:45
renders of the process I borrowed from
5:47
St ass's online promotional videos so
5:49
let's run through it as you may imagine
5:51
the slicer application is proprietory
5:54
you simply throw the colored model into
5:56
the application and tell it to orient
5:58
the model for you there's no no need to
6:00
add any supports to the model but I'll
6:01
explain the support material shortly now
6:04
even on a small laptop this process was
6:07
incredibly fast and once that's done you
6:10
just send the print to the printer
6:11
wirelessly now in this process there are
6:14
a load of options to choose depending on
6:16
the materials the machine is using but
6:18
because this one is used in a production
6:20
environment doing pretty much the same
6:21
task of printing colored models over and
6:23
over we can skip all this but you can
6:26
actually select the surface finish too
6:28
which is either Satin or gloss and
6:30
that's kind of cool now once the model's
6:32
on the printer you just tell it to start
6:34
the print and from here this spinning
6:36
plate will move upwards to what I will
6:39
just call the printing components you
6:42
see there's multiple here and as the bed
6:44
spins each of these components performs
6:47
its particular task though it's not a
6:49
case of all of these operating with
6:51
every rotation it's done in various
6:53
stages so first on the left we've got
6:55
the print heads and in a similar way to
6:57
how inkjet printers work the these will
6:59
lay dots of UV curing material on the
7:02
surface of the spinning print bed now
7:05
whilst this is essentially UV curing
7:07
resin it's referred to as ink and just
7:10
like an inkjet printer these colored
7:12
inks are mixed with black and white to
7:14
give us the 640,000 different color
7:17
tones that this machine is capable of
7:19
producing but this is only the outer
7:21
surfaces of each layer approximately 200
7:24
microns in depth into the actual model
7:27
the internal material is made up of
7:29
either pure black or Pure White if you
7:32
actually snap one of these models when
7:33
it's printed you can see the core
7:35
material is actually a single color and
7:38
the print heads will also lay down the
7:39
support material which is used as both a
7:42
base and completely supports and
7:44
surrounds the model from underneath and
7:46
the sides there's no support gantries
7:49
with contact points on the model this is
7:51
a complete and gapless support bed for
7:54
every part of every surface on every
7:56
layer and this can easily be REM removed
7:59
after printing so as the plate spins
8:02
past these print heads they lay down the
8:04
dots and then retract into the body of
8:06
the printer and that's against an
8:08
internal wiper to clean them for the
8:10
next layer and then they pass a roller
8:13
which is similar to the ones used in
8:14
laser printing the ink is negatively
8:16
charged the roller is positively charged
8:18
it might be the other way around but you
8:20
get what I mean and this is used to pick
8:22
up any stray microns of excess material
8:25
droplets before it gets cured and this
8:28
is always running throughout the print
8:30
the final stage is the LED curing bar
8:33
which like the print heads move between
8:35
the inner and outer planes of this disc
8:37
and they light up to cure and Harden the
8:40
dots in place again it does not appear
8:42
that all of these sequences occur in a
8:44
single rotation but I'm not 100% clear
8:47
on the process if it does a particular
8:48
set of colors in one pass then an
8:50
internal material then support material
8:53
then a couple of cure passes but what I
8:55
do know is this prints damn fast now
8:58
whilst this print printers capable of
9:00
layers as low as 18 microns the model I
9:03
had printed was at the pretty accepted
9:05
standard of 50 microns and that was
9:07
complete in just over 7 hours making the
9:10
speed of this printer pretty comparable
9:13
to most home printers now suffice to say
9:16
I'm incredibly impressed by what this
9:18
style of Technology can achieve in terms
9:20
of speed yes monocolor resin prints are
9:22
getting faster now but for the amount
9:25
this does the time it does it in is
9:27
genuinely astounding but I think the
9:29
most impressive part is the thing we
9:31
don't currently have in most printers
9:33
and is also the thing that puts a lot of
9:34
resin printing adopters off is that once
9:37
this is all done on this machine the
9:39
model is free to handle with bare skin
9:42
and it's at this point encased entirely
9:45
within the wax-like support material now
9:47
before showing the cleaning I just want
9:49
to quickly talk about the maintenance
9:51
process which only games run through
9:53
after every single print now this isn't
9:56
automated nor does it self detect when
9:58
it's clean but the printer shows you a
10:00
checklist of things to clean in a
10:01
particular order and to do this you need
10:04
a very special type of cloth to prevent
10:06
any stray fibers from getting into the
10:08
machine's mechanics a couple of dabs
10:10
with isopropanol and then it's a case of
10:12
wiping down the print heads the roller
10:14
the print head wiper the UV lamp and
10:17
finally the build tray once this is all
10:19
complete you're ready for your next
10:21
print but for us this is where we took
10:23
the model or models to go off and have
10:25
the support material removed now this
10:28
model as I said in my than my mini
10:30
Factory video which may be out before or
10:32
after this I don't know I asked for this
10:34
model in order to feed my own ego so I
10:37
had a model sculptured by my friends at
10:39
Titan Forge around my head scanner had
10:42
done one that I've actually printed in
10:43
previous videos so you've seen it now
10:45
they added some signature elements like
10:47
my hoodie a bottle of wargamer resin and
10:49
an Artis Opus dry brush and whilst I'm
10:51
stood on a pile of boxes I like to
10:53
imagine these as futuristic 3D printers
10:56
now the colors on this render were based
10:58
on my previous profile picture that I
11:00
had commissioned several years ago and
11:02
this model was digitally painted by
11:04
printed Obsession they have done a
11:06
number of digital paint jobs on various
11:08
models which you can actually already
11:10
order directly from only games so if
11:13
you're enjoying this content don't
11:15
forget to check out both Titan Forge and
11:17
printed Obsession along with only games
11:19
and as usual links are down in the
11:21
description so as I've teased a couple
11:23
of times already and I hope I haven't
11:25
kept you waiting too long like most
11:26
people winge about in comments I don't
11:28
mind those comments feeds the YouTube
11:30
algorithm keep complaining about me I
11:32
love it anyway on to cleaning the
11:34
cleaning process on these models is
11:36
incredibly straightforward to the point
11:38
where many of you will look at it and
11:40
think God I wish I had that at home
11:42
that's amazing so no joke it's a simple
11:45
case of popping it into an ultrasonic
11:46
cleaner with water no isopropanol or
11:49
crazy chemicals just normal water and
11:52
when this is heated and the Ultrasonic
11:54
Cleaner is turned on all of the wax-like
11:56
support material is cleared away leaving
11:59
nothing but the complete un colored
12:01
model beneath it and because the model
12:03
had every single surface supported
12:06
there's no support marks anywhere just a
12:08
pure and pristine model surface that is
12:10
printed as though it was perfectly
12:12
suspended and cured in midair please
12:15
tell me you're not impressed by that
12:17
alone forget the color tell me you're
12:19
not impressed by the technology and how
12:22
this is just printed perfectly no
12:24
support marks cleaned in nothing more
12:27
than water and an ultrasonic cleaner
12:29
and you've got a perfect model tell me
12:32
that's not amazing go on please the
12:35
comments are down there can you do it
12:37
really is anybody out there saying oh no
12:40
this is horrible seriously anyway this
12:43
is all promo really isn't it I haven't
12:45
been paid to make this video but I got a
12:47
free model out of it that's cool now if
12:50
you're interested and you think it's
12:51
cool and you want to see this finished
12:53
colored model in person it along with
12:56
numerous other colored models will be on
12:58
display at UK games Expo 2024 which is
13:01
when color printing on only games will
13:03
be officially launched I'll be wandering
13:06
around at the event too so please come
13:07
up and say hi tell me your printing and
13:10
painting stories and I'll have dozens of
13:12
miniature versions of this sculpt to
13:14
give away too all it costs is a polite
13:16
hello and asking for one however if you
13:19
are going I will be there with my family
13:20
on the Friday as it's my kids first con
13:23
so forgive me if I need to be a little
13:24
more brief on that day I'll be more free
13:27
on the Saturday and the Sunday speaking
13:29
of the best time for a meet will be the
13:31
Sunday when I'll actually be at the my
13:33
mini Factory Booth doing some painting
13:35
demos but if you can't make it there or
13:37
maybe it's in a different country and
13:39
you're not going I'll be taking these
13:40
models to Future cons too like Gen Con
13:43
Nova Spiel where I'll most likely be at
13:45
the artist Opus Booth doing painting
13:47
demos but before I go I want to know
13:51
seriously honestly what do you think
13:54
about this technology now I worry that
13:57
existing miniature artists could
13:59
interpret this as a threat to their work
14:01
but I honestly find that quite unlikely
14:04
as in it's not going to be a threat in
14:06
fact the opposite like look at the 2D
14:09
art world now where companies are
14:10
selling their poster prints of famous
14:12
artists work the original Works values
14:15
have
14:16
skyrocketed this technology suggests a
14:18
future where more people could actually
14:20
own a full 3d copy of models as artwork
14:25
but even scans of models painted by
14:27
their favorite artists like an hel
14:29
geraldez Darren leam Richard Gray David
14:32
SOA and more I'm not saying they would
14:34
want to get involved in this I'm just
14:36
saying imagine owning just a piece of
14:41
their greatness or a copy of their
14:43
greatness in your own home if that's
14:45
your cup of tea I'd love it I think it'
14:47
be fantastic but the thing is like my
14:50
mini Factory has already become a place
14:53
where people in this hobby can not only
14:54
showcase and celebrate but even earn
14:57
from their Creations you've got digital
14:59
sculptors and rle makers selling their
15:01
things you've got the people who paint
15:03
them getting paid tips just for pictures
15:05
they've uploaded to the platform now
15:07
imagine a future where you can actually
15:10
paint a model have it 3D scanned and
15:13
sell that digital paint job to me this
15:16
brings the world of creative people
15:18
closer together and when it's done right
15:20
as I trust my minifactory to do because
15:23
they're all about Community it allows
15:25
different creators work to be enjoyed by
15:28
a much wider audience of people love
15:30
this or hate it like any new technology
15:33
like AI there's no putting this Genie
15:35
back in the bottle it's out there now
15:37
it's available and this is just the
15:39
beginning I expect one day very soon
15:41
you'll be able to order an entire War
15:44
Games force of figures in the exact
15:46
color scheme and style that you want but
15:49
like I was saying what do you think I
15:51
think you can tell I'm a bit over
15:53
excited about it but if there's been any
15:56
pattern in my videos since I've started
15:57
this channel it's I'm happy when
15:59
technology leaps forward and I'm unhappy
16:02
when technology could have been done
16:03
better and this is one giant leap in my
16:07
eyes if nothing more I'm at least
16:09
looking at this as a prophecy to the day
16:11
where home 3D printing at least gives us
16:14
some of these features and benefits I
16:16
don't mean color so much as the closed
16:18
resin feed the ability to fully support
16:20
models without having support marks and
16:23
cleanup at least not clean up that's
16:25
little more than dissolving the support
16:27
solution in a bath of hot water it's
16:30
coming guys in fact it's already here
16:32
check out only games for their ever
16:33
growing selection of models and as
16:36
always I've got links in the description
16:39
and if you want to buy one of these
16:40
printers I'd love to say click my
16:42
affiliate link so I can earn a
16:43
commission I'd love to earn a commission
16:45
on one of these they cost that much it
16:47
would feed my family for a couple of
16:49
months now at least at the time of
16:51
recording I have no affiliate link but
16:52
I'll put a link to the printers below
16:54
this video and if you're watching this
16:56
please let me have an affiliate link St
16:58
assist I think that would be you know
17:00
great I'd love it thank you I'd be able
17:03
to do more videos faster anyway thanks
17:06
everyone for watching and thanks to our
17:07
members who support us financially each
17:09
month and they get early access to
17:11
videos like this and their name in the
17:13
credits so until next time we all go a
17:16
little mad sometimes see you guys F
17:18
hammer out
17:21
[Music]
