i get a load of messages every week and
0:02
they tend to fall into one of two camps
0:04
either I just got a new resin printer
0:06
and everything keeps failing or I've had
0:08
my printer a while and suddenly
0:10
everything keeps failing yet there's
0:12
nothing in between it's like printers
0:14
have a grace period and then
0:15
spontaneously develop a trauma and these
0:18
messages nearly always come with the
0:19
same attachments pictures of the exact
0:21
same kind of failure or screenshots of
0:23
slicer settings I've seen more times
0:25
than I can count and weirdly the
0:27
problem's usually obvious once you've
0:29
seen it enough so I hope this video
0:31
helps you but if it doesn't help you
0:33
then well at least it'll help me because
0:36
now when someone asks me again I can
0:38
just paste them this link to avoid
0:39
rewriting it for the teenth time so
0:42
let's crack on hi I'm Ross this is
0:44
Fammer Videos and all of that's obvious
0:46
because you can see the channel name
0:48
below the video now if you've got a
0:50
resin printer one of the first things
0:51
you're told is to dial in your exposure
0:53
time and my last video covered exactly
0:55
that and yes I prefer to aim for print
0:57
success first and accuracy second
0:59
because if it doesn't print at all who
1:01
cares how accurate it might have been
1:03
but yeah what happens if you're getting
1:05
the prints that start great and the base
1:07
layers stick the supports are going
1:09
strong but then out of nowhere your
1:12
model looks like it's lost a jewel with
1:13
a guillotine halfway through printing
1:15
now in my experience over 95% of the
1:18
time I've helped someone with this the
1:20
answer is one specific setting okay
1:23
actually it's two all right fine it's 16
1:26
we're talking about lift height and lift
1:28
speed yes just those two but also the
1:31
variations for base layer normal layer
1:33
lift retract yeah so it's 16 in total
1:36
and I'm sorry but fix your printer with
1:38
these 16 settings just doesn't make a
1:41
clickable video so I do what I have to
1:43
do look hate the player not the game all
1:45
right fine hate the player i probably
1:47
deserve it anyway let's talk about
1:49
what's happening most of us know resin
1:52
printing works by curing layers of resin
1:54
stuck to the build plate and then after
1:56
that stuck to the previous layer the
1:58
release film at the bottom the FAP NFAP
2:01
ACF whatever the release film is called
2:03
is designed to be optically clear and
2:05
not hold onto the resin you want your
2:07
cured layer to stick to the plate or
2:09
last layer not the film so as the bed
2:12
lifts the cured resin peels off the film
2:15
if it lifts too fast it can actually
2:17
yank the print apart if the lift height
2:19
is too low the resin doesn't
2:21
successfully separate from the film and
2:23
you don't create a proper gap for fresh
2:25
resin to flow into so the next layer's
2:28
got nowhere to go and when the release
2:30
film finally does disconnect you've
2:32
basically created a void in your model
2:34
and that's where the tear begins now
2:37
here's the sneaky bit and why it doesn't
2:38
always happen on new machines and why it
2:40
often creeps in after a few weeks or
2:42
months is because your release film has
2:45
started to stretch more than likely in
2:48
the middle and why the middle well
2:50
because that's where every slicer drops
2:52
the models by default but again that's
2:54
also furthest from the edge so it
2:56
doesn't really matter how many models
2:57
you've got on there but they will
2:59
stretch from the edges to the center the
3:02
point is as your film wears you're more
3:04
likely to get these kinds of failures
3:06
and if you're printing a full plate edge
3:07
to edge then surface tension gets
3:10
stronger because you're pulling away a
3:12
much larger cured area all at once but
3:14
how do we fix it well the simple answer
3:16
is you slow down your lift speeds and
3:18
you increase your lift height not
3:20
dramatically sensibly now most modern
3:22
printers have something called two-stage
3:24
motion control or TSMC if yours doesn't
3:27
I probably hate it deeply passionately
3:30
except when I don't but we'll come back
3:32
to those two examples later so TSMC
3:35
lifts the bed in quite obviously two
3:38
stages first slowly to gently peel the
3:41
layer away from the edges then faster to
3:43
clear the space and let new resin flow
3:45
in and it's the same deal in reverse
3:47
where the bed lowers or retracts fast
3:50
until it gets close and then slow to
3:52
ease the model back towards the screen
3:54
now Eligu's new satellite slicer
3:56
actually has a great pop-up graphic
3:58
showing this as a visual when you select
4:00
each setting i just wish it were larger
4:02
so you could actually read the text and
4:04
know what each of the stages represents
4:07
but anyway once you understand what it
4:08
does the motion control settings make
4:10
obvious sense and you shouldn't ignore
4:12
them due to complexity it's actually
4:14
pretty simple just a bit convoluted and
4:17
the reason there are 16 settings is
4:19
because well okay you've got two sets of
4:22
eight lift distance for stages one and
4:24
two with corresponding lift speeds for
4:27
those two stages that's four settings
4:29
and retract is exactly the same but in
4:32
reverse so another four settings makes
4:34
eight but this is also copied between
4:37
base layers and normal layers so there's
4:39
your 16 now you could have faster speeds
4:42
for normal layers sure but do I bother
4:45
honestly no more often than not I just
4:48
match them i'm not chasing speed i'm
4:50
dialing in for success now for anybody
4:52
asking for the TLDDR or get to the point
4:54
here's a screenshot of the settings I
4:56
use on 6 in 10in and 13-in printers
4:59
these aren't gospel but they're a bloody
5:01
good starting point and I know people
5:03
will scream in the comments "That's too
5:05
slow that's too high." Yeah I know
5:07
you're not wrong but these settings
5:09
haven't failed me on a single printer
5:11
I've tested and if they ever have it's
5:14
not because of the settings it's
5:15
typically because the release film is
5:17
just a bit worn out so when that happens
5:19
I just bump the lift height up by 1 mm
5:22
for each stage and carry on and when it
5:24
comes to speeds I typically set the
5:26
stage 1 lift speed to 60 mm a minute
5:28
because that's the same as 1 mm/s
5:32
easy then stage two goes up in multiples
5:34
of 60 mm a minute because that's equal
5:37
to how many millm a second it is again
5:39
just because it's tidy and makes the
5:41
math simple there's no magic behind it
5:43
just habits and logic in my head that
5:46
make it work but anyway the point is you
5:48
should now understand what these
5:50
settings do and why these problems arise
5:52
so feel free to tweak them and if you've
5:54
got suggestions drop them in the
5:56
comments that's going to help other
5:57
people who come here looking for advice
5:59
let's be fair you as a community are
6:02
probably much smarter than me but in
6:03
fairness an individual being smarter
6:05
than me isn't a high bar anyway a quick
6:08
note before we wrap yes this video was
6:10
sponsored by Eligu i explained how all
6:12
that works in the last video so I'm not
6:14
going to repeat myself but keep in mind
6:16
if you are using the Mars 5 Ultra or the
6:18
Saturn 4 Ultra those printers actually
6:21
use tilting bat so you don't have these
6:23
settings if you do get issues like we've
6:25
shown here I don't want you to feel like
6:27
this was a pointless video for you so in
6:30
that case just switch your printer's
6:31
tilt mechanism from fast mode to slow
6:33
mode in the UI and that should help but
6:35
I would love to see a future version of
6:37
this mechanism that both tilts and lifts
6:39
and retracts that would be absolutely
6:42
glorious and if you're still having a
6:43
problem like this well it could be layer
6:46
compression in which case we need to
6:47
look at weight speeds but that'll be
6:49
another video assuming Eligu continue to
6:51
sponsor me but anyway if you've seen
6:53
someone with this issue please share the
6:55
video with them it might help them and
6:57
it'll definitely help me because more
6:59
views means more content like this which
7:01
we both want right anyway I want to say
